Specification
| General specifications | |
| Operating system | Windows 8/8.1/10/11 macOS 10.13 and higher. Android v9 and higher (ClickShare App)* iOS 12 and higher (ClickShare App)* |
| Video outputs | 4K UHD (3840*2160) @ 30Hz. HDMI 1.4b |
| Audio output | HDMI |
| USB | 1 X USB-A, 1 X USB-C |
| ClickShare Buttons | 1 |
| ClickShare App | Desktop & Mobile |
| Native protocols | Airplay, Google Cast, Miracast* |
| Maximum number of simultaneous connections (with Buttons and/or App) |
32 |
| Noise Level | Max. 25dBA @ 0-30°C Max. 30dBA @ 30-40°C |
| Authentication protocol | WPA2-PSK in stand alone mode WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode |
| Wireless transmission protocol | IEEE 802.11 a/g/n/ac and IEEE 802.15.1 |
| Reach | Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit Frequency band 2.4 GHZ and 5 GHz |
| Frequency band | 2.4 GHZ and 5 GHz (DFS channels supported in select number of countries) |
| Connections | 1x Ethernet LAN 1Gbit 1x USB Type-C 2.0 (front); 1x USB Type A 2.0 (front) |
| Temperature range | Operating: 0°C to +40°C (+32°F to +104°F) Max: 35°C (95°F) at 3000m Storage: -20°C to +60°C (-4°F to +140°F) |
| Humidity | Storage: 0 to 90% relative humidity, non-condensing Operation: 0 to 85% relative humidity, non-condensing |
| Anti-theft system | Kensington lock |
| Certifications | FCC/CE |
| Touch screen support & Interactivity | Yes |
| Room Dock (peripheral support) | No |
| Local view | Yes |
| Network connection | LAN & WiFi |
| Management and reporting | Yes |
| ClickShare Base Unit dimensions | |
| Dimensions (HxWxD) | 34 mm x 135 mm x 135 mm |
| Power supply | Standard 110/220 V AC plug |
| Power consumption | Operational: 5-10W, 24W Max |
| Weight | 900 gr |
