| Light source | Light source | 400W LED | |
| Lifespan | 20,000 hours | ||
| CCT | 6800K | ||
| Control parameters | Optical path lens | 3° to 38° | |
| Strobe | Electronic stroboscopic 1-30 times/second, support pulse stroboscopic + effect stroboscopic + random stroboscopic | ||
| Dimming | Linear dimming | ||
| Control signal | DMX512(Digital MultipleX 512)+RDM | ||
| Control channel | 19CH | ||
| Operation mode | Console, manual, master/slave | ||
| Light source heat dissipation | using internal circulation + copper tube heat conduction technology, active heat dissipation, to ensure that the product is more stable | ||
| Color | 1pcs color disc: 12 high-gloss coating colors + white light | ||
| Gobo | 1pcs metal gobo plate: 11 gobos + white light, with shaking, flow effect 1pcs glass gobo plate: 7 patterns + white light, with shaking, flow effect |
||
| Prism | 1pcs 3 prism +1pcs 4 prism, can be independently rotated, with two-way variable speed rotation effect | ||
| Six-color wheel | 6 high-gloss coating colors, with prism can produce six-color prism effect | ||
| Frost | 1 independent frost sheet, which can be converted to dyeing effect | ||
| Scanning | horizontal 540 degrees 3.2S/ cycle, vertical 270 degrees 1.3S/ cycle, three-phase motor, using photoelectric reset + Hall correction double precision reset, so that positioning is more accurate, while automatic error correction, with automatic return function | ||
| Display function | TFT LCD screen, screen can be reversed, switch between Chinese and English, automatic screen off/permanent screen, can display bright bubble time, fault detection, software version information, fan speed, can be restored to factory Settings | ||
| Safety protection | Automatically cut off the power supply when the body overheats or the system fails | ||
| Working parameters | Working voltage | AC100V-240V (50/60HZ) | |
| Rated total power | 550W | ||
| Power factor | 0.99 | ||
| Maximum operating temperature | 40 degrees | ||
| Light parameters | Display | TFT LCD display +4 touch buttons | |
| Power interface | waterproof twist brittle head, one in one out | ||
| Signal interface | waterproof signal socket 3-core male + female | ||
| IP rate | IP66 | ||
| Net weight | 30.5KG | ||
